FDA Automated Fundus Camera 35mm Fluorescence Angiography

FDA Automated Fundus Camera 35mm Fluorescence Angiography

FDA Automated Fundus Camera

50 degrees Automated Fundus Camera

35mm fundus photography machine

Place of Origin:

China

Brand Name:

SYSEYE

Certification:

FDA

Model Number:

RetiCam 3100

Contact Us

Request A Quote
Product Details
Product Name:
Fluorescence Angiography Automated Fundus Camera
Size:
380mm(L)x550mm(W)x475mm(H)
Weight:
26.5Kg
Field View:
50°
Working Distance:
35mm
Minimum Pupil:
≥3.3mm
Focus Modes:
Manual/Auto
Feature:
Photography Fundus And Fluorescence Angiography
Payment & Shipping Terms
Minimum Order Quantity
1
Price
$12,000.00-$13,000.00
Delivery Time
5 working days
Payment Terms
, T/T
Supply Ability
100
Product Description

photography fundus and fluorescence angiography (FFA optional) Automated Fundus Camera



Fundus fluorescein imaging is a very important means of examining fundus diseases in ophthalmology. Fundus angiography is to inject a certain concentration of contrast agent into the body, through the blood circulation to the visual fundus retina, choroid, take photos in time, to observe the retina, choroid blood supply, whether there is abnormal blood vessels, whether there is inflammation and atrophy of retina, choroid. Automatic Fundus Camera Reticam 3100 can further clarify the nature and extent of fundus lesions, and provide a good objective basis for the formulation of treatment plans in the next step.



non-mydriatic Automated fundus camera RetiCam 3100 can be used to capture the anterior and posterior eye images. It has a field of view of 50 degrees for fundus imaging.



Automatic Fundus Camera Reticam 3100 is a highly recognized and popular automatic fundus imaging system around the world. Through dual camera imaging, image control and feature recognition, eye XYZ 3D automatic positioning is realized. Through CCD imaging feedback, the exposure is measured, and the exposure intensity is automatically and accurately determined, without the need for a doctor's complex operation. By controlling the focusing step length according to the image resolution, the image definition can be automatically adjusted to obtain a clear and accurate fundus image and help doctors make accurate judgments for patients.





Acquisition Modes Automated Fundus Camera/mydriatic Anterior photography /Red-free(optional)(FFA)/(FAF)
Field View 50°
Working Distance 35mm
Minimum Pupil ≥3.3mm
Focus Modes Manual/Auto
Alignment Modes Double dots auxiliary
Exposure Manual /Auto
Photography SLR Camera
Image definition 24 Megapixel
Compensation ±25D
Fixation External /Internal (any position available)
DICOM 3.0 Support





                                               Automated Fundus Camera in the world
Brand TOPCON(NW-400) DRS NEWVISON(RETICAM3100)
operation automatic(one key taking picutre)/manual automatic(one key taking picutre)/manual automatic(one key taking picutre)/manual
Acquisition modes fundus/anterior/? fundus/anterior/red-free filter fundus/anterior/red-free filter/FFA(optional)/FAF(optional)
Filed of view 45 degree 40-45degree 45-50degee
Mosic degee   80 degree 135degree
Minimum pipil size 3.3mm 3.5mm 3.3mm
Resolution above 18megapiexl sensor size:5 megapixel sensor resoultion: 48 pixel/degree above18 megapixel (24 megapixel optional )
Fixation 9 internal + 1 outside fixaiton 7 internal fixation countless fixaiton, any position is available during range + 1 outside fixation
Technology of focus     Dual camrea technology
exposure ligh standard standard new technology, more soft, one patient same eye can take picuture consecutive with almost same performace

FDA Automated Fundus Camera 35mm Fluorescence Angiography 0

FDA Automated Fundus Camera 35mm Fluorescence Angiography 1





FDA Automated Fundus Camera 35mm Fluorescence Angiography 2

Company Introduction

FDA Automated Fundus Camera 35mm Fluorescence Angiography 3

Focusing on the two major public health problems of adolescent myopia and elderly ophthalmology, our company researches new diagnostic and treatment equipment for ophthalmology, develops low-cost applicable technology products, realizes industrialization, reduces the cost of social medical and health system, and serves the strategic needs of national health.The company always adhere to the "high-tech,new vision" for the enterprise development concept.We have a strong technical force, has been awarded 11 patents, and obtained 13,485 quality system certification.Bio has established an efficient marketing team and a perfect after-sales service system to provide medical equipment with the highest cost performance and meticulous service.

FDA Automated Fundus Camera 35mm Fluorescence Angiography 4
