Digital Fundus Dual Camera System 9 Position Mosaic Small Pupil Mode

Digital Fundus Dual Camera System 9 Position Mosaic Small Pupil Mode

digital fundus dual camera

9 Position Mosaic fundus camera

Small Pupil Mode Fundus camera

Place of Origin:

China

Brand Name:

SYSEYE

Certification:

FDA

Model Number:

RetiCam 3100(Mini)

Contact Us

Request A Quote
Product Details
Product Name:
Near-Infrared Light Imaging Technology Non Mydriatic Fundus Camera
Classification By Operating Mode:
Continuous Operation
Input Power Of Medical Electrical Equipment:
200VA
CPU:
1.6GHz
Working Distance:
17mm
Minimum Pupil Size:
≥2.8mm
Field Of View:
50°
Feature:
Near-Infrared Light Imaging Technology
Payment & Shipping Terms
Minimum Order Quantity
1
Price
$7,500.00-$8,300.00
Packaging Details
380mm(L)x550mm(W)x475mm(H)
Delivery Time
5 working days
Payment Terms
T/T
Supply Ability
100
Product Description

digital fundus camera dual camera system 9-position mosaic small pupil mode



Kestrel 3100m can photography the retina, i.e. neurosensory tissues of eyes, and then convert the captured optical image into electronic pulses that can be understood by the brain. Pupils serve as both the inlet and outlet of light for illumination and imaging of Kestrel 3100m, thus monitoring the fundus. Patients shall put the chin on the chin rest and lean the forehead on the forehead rest. The operator shall operate it manually to focalize and align to the fundus, and capture the fundus images upon clicking, with such images directly shown on the touch screen. Ophthalmologists will trace the progression of eye diseases on the basis of such retinographs, which will serve as the basis of diagnosis and treatment.



Specification of Non Mydriatic Fundus Camera

Acquisition modes
Non Mydriatic Fundus Camera
Field of view
50°
Working distance
17mm
Minimum pupil size
≥2.8mm
Focus modes
Auto/manual
Exposure modes
Auto /manual
Operation
Auto /manual
Photography
SLR camera
Camera
CCD
Diopter compensation
±25D
Fixation
External fixation / internal fixation
Autofocus assist light
Infrared LED
DICOM 3.0
Yes
Customization AI port
Yes



Working principles of Non Mydriatic Fundus Camera

RetiCam 3100, based on near-infrared light imaging technology, can capture the required visible light images of fundus exposed to visible light within milliseconds (no enough time for pupils to shrink).

What are features of our Non Mydriatic Fundus Camera ?

1. Onc-key touch, picture got automatically

2. Double cameras system, get focus position accurately and quickly

3. Non-mydriatic,automatic focus,automatic exposure

4. Smart operation:automatic,simple,fast

5. 10.1 inch TFT touch-color screen with concise interface design,each indication presented clearly



Digital Fundus Dual Camera System 9 Position Mosaic Small Pupil Mode 0







Company Introduction

Digital Fundus Dual Camera System 9 Position Mosaic Small Pupil Mode 1

Focusing on the two major public health problems of adolescent myopia and elderly ophthalmology, our company researches new diagnostic and treatment equipment for ophthalmology, develops low-cost  applicable technology products, realizes industrialization, reduces the cost of social medical and health system, and serves the strategic needs of national health.The company always adhere to the "high-tech,new vision" for the enterprise development concept.We have a strong technical force, has been awarded 11 patents, and obtained 13,485 quality system certification.Bio has established an efficient marketing team and a perfect after-sales service system to provide medical equipment with the highest cost performance and meticulous service.
