Name: SYSEYE RetiCam 3100 Digital Fundus Camera with 1.3 Magnification 26.5Kg Weight and 90 mm Stage Movement for High Precision Retinal Imaging
Brand: Chongqing Bio Newvision Medical Equipment Ltd.
SKU: RetiCam 3100
Price: 12 USD
Availability: InStock

Home > Products > Digital Fundus Camera >

SYSEYE RetiCam 3100 Digital Fundus Camera with 1.3 Magnification 26.5Kg Weight and 90 mm Stage Movement for High Precision Retinal Imaging

Retinal Imaging Digital Fundus Camera

Small Pupil Mode Digital Fundus Camera

Digital High Resolution Fundus Camera

Place of Origin:

China

Brand Name:

SYSEYE

Certification:

FDA 510(k): K190954

Model Number:

RetiCam 3100

Request A Quote

Product Details

Minimum Pupil:

≥3.3 Mm

Field Of View:

50°

Focus Modes:

Manual/Auto

Product Name:

High Resolution Digital Fundus Camera

Working Distance:

35mm

Magnification:

1.3

Weight:

26.5Kg

Stage:

90 Mm Left And Right, 35 Mm Front And Rear

Payment & Shipping Terms

Minimum Order Quantity

Price

From $12,000 (final price depends on configuration & volume)

Packaging Details

380mm(L)x550mm(W)x475mm(H)

Delivery Time

5 working days

Payment Terms

,T/T

Supply Ability

100

Non-mydriactic Portable Fundus Camera With Compact Design High Definition Images For Ophthalmic Medical Technology

Get Best Price

Ultra Wide Field Fundus Photography Portable Fundus Camera With Compact Design Easy To Carry Features

Get Best Price

Kestrel 300 Portable Fundus Camera With Compact Design High Definition Images For Ophthalmic Medical Technology

Get Best Price

Video

Highly Accurate Retinal Fundus Camera And Easy To Use Digital Fundus Camera

Get Best Price

+8618883882529

xh@newvision-sz.com

86-023-65456660

Contact Now

Product Description

SYSEYE RetiCam 3100 Non-Mydriatic Digital Fundus Camera

Professional retinal imaging system with small pupil capability (≥3.3 mm) and 50° field of view for efficient screening of DR, AMD, and glaucoma.

Key Benefits

Small-pupil imaging: ≥3.3 mm without dilation
Wide field of view: 50° for comprehensive screening and documentation
User-friendly operation: Auto/manual focus with XYZ auto-alignment
Fast availability: Ships in 5 working days with MOQ = 1

Quick Enquiry

Please provide: (1) Your organization type (2) Country/Region (3) Quantity & delivery date (4) Contact details. We'll respond within 12 hours with pricing and demo arrangements.

Standard Configuration

Main unit (RetiCam 3100), chin-rest paper pad, power cable, objective lens cover, dust cover, wireless keyboard & mouse, hood, extension plug, operation manual.

Technical Specifications

Field of view	50° (typical)
Minimum pupil diameter	≥3.3 mm (small-pupil mode)
Resolution (lp/mm)	Center ≥60 \| Edge ≥25
Magnification	1.3*
Working distance	35 mm
Focus system	Auto/manual with ±25 D compensation
Alignment	XYZ auto-alignment
Illumination	IR LED for observation \| Xenon flash for capture
Fixation	Internal LED with external fixation support
Movement range	Stage: 90mm (L/R), 35mm (F/B) Main unit: 30mm vertical Chin-rest: 60mm
Power supply	AC 100-240 V, 50/60 Hz
Dimensions/Weight	380550475 mm / 26.5 kg

Compliance & Connectivity

DICOM-compatible image export for system integration. Manufactured under ISO 13485 quality system.

Clinical Applications

Screening and monitoring of diabetic retinopathy (DR), age-related macular degeneration (AMD), and glaucoma; routine examinations and referral documentation; medical education and case management.
