Children Automatic Tonometer 21mmHg Automatic Eye Measurement

One Automatic Measurement Of The Left And Right Eye Data Automatic Tonometer

Measurement of intraocular pressure can understand the pressure inside the eyeball, because the pressure is too high will lead to compression of the optic nerve, optic nerve atrophy, and even blindness; Pressure is too low, can cause retinal choroid oedema, detachment, final possible eyeball atrophy. Many diseases can be related to intraocular pressure, such as glaucoma, uveitis, ocular trauma, etc. Therefore, the measurement of intraocular pressure is a routine examination of ophthalmology.

The pressure of the contents of the eyeball against the wall of the eye is called intraocular pressure. The normal range is 10-21mmHg, the difference of intraocular pressure is less than 5mmHg, and the fluctuation of intraocular pressure is less than 8 when 24 disappears. Most of the reasons are caused by increased intraocular pressure. The increased intraocular pressure is due to the obstruction of the intraocular aqueous humor drainage system, which leads to excessive aqueous humor remaining in the eye and forming pressure on the ocular wall. Elevated intraocular pressure can easily lead to eye diseases such as glaucoma, so it is necessary to measure intraocular pressure

Automatic Tonometer specification

Product Description Of Automatic Tonometer

Screen color and touch,

Rotating screen like Topcon.

Motorized chinrest

Auto tracking eye , you can select auto or manual .

if select auto , will automatic adjust the chinrest distance , height, and shoot air to measure . two second finish .

Intraocular pressure (IOP) measuring range: 1mmHg~ 30mmHg /1mmHg ~60mmHg ( precision of 1mmHg)
Measuring system: dual sensor system of light and pressure
Working distance:≥11mm
R/L: automatic detection and display
Measuring result: 10 times per eye; 3 times result printing per eye
Recording: build-in printer
Measuring mode: auto/manual
Focus: when luminous spot is in the focus frame, 2 modes can be chosen.
Auto mode: auto intraocular pressure measurement
Manual mode: when it's good focus, the frame will turn yellow into green, and click to start the measurement
Error indication: if the measurement signal is weak, the IOP will be enclosed by ( ), or display “ERR ”
Safety limit button: install measurement for minimum distance between head and patient
Safety functions: the distance between air nozzle and cornea is controlled in preset range(such as 11mm); it will stop going forward when the cornea is too closed to air head.
Movement range:≥30mm(front to back)/ 90mm(left to right)/ 30mm(vertical)
Jaw layer vertical movement: 0~65mm with under jaw layer
Display mode: 10.1-inch HDMI color LED touch monitor
Output port: USB2.0
Working platform: electric elevating platform
