Static Visual Field Analyzer CE Optic Atrophy Real Time Assessment

Static Visual Field Analyzer CE Optic Atrophy Real Time Assessment

CE Visual Field Analyzer

Optic Atrophy Visual Field Analyzer

Real Time automated static perimetry

Place of Origin:

China

Brand Name:

SYSEYE

Certification:

CE

Model Number:

BIO-1000

Contact Us

Request A Quote
Product Details
Product Name:
Provides Real-Time Assessmen Visual Field Analyzer
Size:
412mm ( Length) * 497mm ( Width) * 513mm ( Height )
Weight:
17kg
Power:
100- -240V,50-60Hz
Feature:
Provides Real-Time Assessment Of Eye Fixation
Environment Light Detection:
Automatic
Inspection Range:
90°
Inspection Distance:
30cm
Payment & Shipping Terms
Minimum Order Quantity
1
Price
$2,800.00-$3,200.00
Packaging Details
412mm ( length) * 497mm ( width) * 513mm ( height )
Delivery Time
5 working days
Payment Terms
T/T
Supply Ability
`100
Product Description

Provides Real-Time Assessment Of Eye Fixation Visual Field Analyzer



Methods for diagnosis of optic atrophy of Visual Field Analyzer  is indispensable, because of the change of optic atrophy symptoms have vision, through visual field, will find that the field of optic atrophy patient has a huge central scotoma, farther from the eye section of the optic nerve lesions is the limitation of visual defect, and eyes with in the lesions of the contralateral side hemianopsia.



Features of Visual Field Analyzer



1.  Comprehensive real-time monitoring, heiji-krakau physiological blind spot monitoring. Gaze tracking/head position tracking, automatic measurement of pupil diameter, reduce the impact of pupil effect on visual field detection.

2.  Personalized design, accurate clinical analysis, accurate and rapid examination strategy.

3.  Under international Goldman standard, providing a variety of calssic test procedures and report analysis.

4.  Provide a comprehensive software testing program.





Specifications:

Basic specification

small size Visual Field Analyzer

Inspection range

90°

Inspection distance

30cm

Background light brightness

White 31.5asb

Visual target brightness

1asb--- -10000asb

Visual target size

GoldmannIII

Visual target interval time

200ms

Visual target interval time

Standard or adjustment according to patient reflection

Threshold test model

Center5-°16, center10° -68, 24 -2, 30-2, 30° -60° nasal step

Upper Threshold test model

30°- 40, 30°-76, P-60, 60°-81, 60°-120,190°-135 nasal side

Special detection strategy

Esterman monocular, Esterman binocular . user- customized test, 150P driver monocular fast detection, 150P driver monocular standard detection , upper 36 detection, blind spot detection,150horizontal straightness detection

Pupil size test

Automatic

Fixation monitoring

Blind spot monitoring , eye position eye position deviation alarm, eye deviation curve

Environment light detection

Automatic

Analysis software

Reliability analysis , single vision report, triple vision report, GPA half vision analysis, GPA glaucoma developing analysis , VFI vision index analysis

Operation system

Win7 above



Feature

Visual Field Analyzer

1. Comprehensive real-time monitoring, heiji-krakau physiological blind spot monitoring. Gaze tracking/head position tracking, automatic measurement of pupil diameter, reduce the impact of pupil effect on visual field detection.

2. Personalized design, accurate clinical analysis, accurate and rapid examination strategy.

3. Under international Goldman standard, providing a variety of calssic test procedures and report analysis.





CE Approved Auto Perimeter Price BIO-1000 in China

CE Approved Auto Perimeter Price BIO-1000 in China

CE Approved Auto Perimeter Price BIO-1000 in China

CE Approved Auto Perimeter Price BIO-1000 in China



Company Introduction

Static Visual Field Analyzer CE Optic Atrophy Real Time Assessment 4

Focusing on the two major public health problems of adolescent myopia and elderly ophthalmology, our company researches new diagnostic and treatment equipment for ophthalmology, develops low-cost applicable technology products, realizes industrialization, reduces the cost of social medical and health system, and serves the strategic needs of national health.The company always adhere to the "high-tech,new vision" for the enterprise development concept.We have a strong technical force, has been awarded 11 patents, and obtained 13,485 quality system certification.Bio has established an efficient marketing team and a perfect after-sales service system to provide medical equipment with the highest cost performance and meticulous service.
