Glaucoma Diagnosis Projection Perimeter TUV Automated Visual Field Test Machine

Glaucoma Diagnosis Projection Perimeter TUV Automated Visual Field Test Machine

TUV Static Projection Perimeter

TUV Projection Perimeter

TUV Glaucoma Automated Visual Field Test Machine

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Product Name:
Make Glaucoma Diagnosis Easier Higher Stability Projection Perimeter
412mm(length)* 497mm(width)* 513mm(height)
100-240V HZ:50-60Hz
Testing Scope:
Testing Distance:
Make Glaucoma Diagnosis Easier
Visual Target:
Red ,blue
Payment & Shipping Terms
Minimum Order Quantity
Packaging Details
412mm(length)* 497mm(width)* 513mm(height)
Delivery Time
5 working days
Payment Terms
Supply Ability
Product Description

Make Glaucoma Diagnosis Easier Higher Stability Projection Perimeter​
Projection Perimeter​ Patient Instructions for Static Testing "If you want to rest, hold down on the button (demonstrate to patient). The test will resume whenyou release the button. We test one eye at a time. Blink normally so your eye does not get dry. Agood time to blink is whenever you push the response button. When your test is over, you will heartwo beeps. You may sit back at that time."
Technical Specification of Projection Perimeter

Testing scope90°
Testing distance30CM
Background lightwhite31.5asb,yellow315asb
Visual target0.08asb---10000asb(0-51DB)
Target sizeGoldmannⅠ, II ,III,IV,V
Visual target stimulation time200ms
Visual target interval timeStandard and custom
Threshold policyMacula,10-2,24-2,30-2,60-4,nasal side
Upper threshold policyC-40,C-64,C-76,FF-81,FF-120,FF-135……
Special detection strategyEsterman monocular,Esterman binocular,upper36°screening,blind point testing
Yellow-blue testingStandard 440nm blue visual target + 315asb OG530yellow background brightness
Visual targetRed ,blue
Dynamic policyStandard dynamic,blind dynamic,dark spot dynamic ,straight line dynamic
Custom policyStatic custom dynamic custom
Pupil size measurementAuto
Fixation monitoringPhysiological blind spot monitoring,eye position monitoring,eye position moving alarm,eye tracking curve
Environment light testingAuto
Analysis softwarereliability analysis , single report, triple report, GHT glaucoma semi vision report, GPA glaucoma developing analysis, VFI analysis, Blue-yellow analysis
SystemWin7 above
Size412mm(length)* 497mm(width)* 513mm(height)

100-240V HZ:50-60Hz

Feature of Projection Perimeter
* Rigorous implementation of Goldman international standard.
* Accurate and elaborate database of normal population of all age groups, recognition of more subtle early visual field defects.
* GHT glaucoma semi vision analysis, make glaucoma diagnosis easier.
* GPA glaucoma progression analysis upgrade, slight glaucoma development is obvious strategy, 30° range visual field inspection only takes 3 minutes.
* Projection Perimeter Simple one-stop modular software design, equipment operation learning only 2 minutes
*.Zeiss humphrey 860 same function
Since Projection Perimeter is a precision instrument ,always use and keep it in a normally conttolled living Environment, within a temperature range of 10-40℃, humidity levels between 40%-80% and an atmospheric pressure range of 760hPa-1060hPa. The instrument should also be placed away from direct sunlight.
 To ensure smooth operation, install the instrument on a level floor free of vibrations.
Also, do not place anything on the instrument.
 Connect all cables properly before using.
 Use the power at rated voltage.
 When not in use, switch off the power source and apply the rubber cap and dust cover.
